Real 700W RMS power capacity
Natural sound and incredible holographic reproduction
Optimized for smooth frequency response in and out axis
Transmission Line Technology
Premium custom CELTO Acoustique Drivers
Proprietary 80ºx50º rotatable 6th order Polynomial horn
Birch plywood cabinet with tongue & groove assembly
Multiple M8 flying points for versatile installation
| Power Handling (AES Standard) | 700W RMS / 2800W Peak |
| Nominal impedance | 8 ohms |
| Frequency response (-6dB half space, no EQ) | 37~20000Hz |
| Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz |
| Average Sensitivity | 99dB/W/m (wideband 200~16000Hz) |
| Maximum Calculated SPL @ 1m | 128dB RMS / 134dB Peak |
| Nominal Directivity (-6dB) | 80° x 50° above 1200Hz |
| Recommended low cut filter | 33Hz 24dB/oct in full range mode, 60-140Hz with subwoofer |
| Low Frequency driver | 15″ CELTO driver, Ferrite magnet, 3.6” In / Out Voice coil |
| High Frequency driver | 1” exit CELTO driver, Ferrite magnet, 1,7” Voice coil, HSP Annular Ring Radiator |
| Crossover | Passive mode only 1400Hz, 12dB/oct on LF,18dB/oct on HF |
| Flying hardware | 9 M8 points |
| Connectors | 2x NEUTRIK Speakon® NL4MP (1+/1- Link, 2+/2- Input & Link) |
| Floor Monitor use | No |
| Pole mount | 35mm dual top hat |
| Cabinet | CNC made with tongue and grove assembly, 18mm birch plywood |
| Finish | Textured Waterborne Black coating, PU foam behind Front grill |
| Size (WxHxD) | 410x720x450 mm net, 530x840x540mm gross |
| Weight | 28g net, 34kg gross |
PM15 loudspeaker system is suitable for near field main PA reinforcement with or without subwoofer, permanent installation.
Suitable for:
PM15_A0_CAD_2D_WEB.pdf
PM15_A0_CAD_2D_WEB.dwg
